SMC composite material is the abbreviation of Sheet Molding Compounds, which is sheet molding compound. The main raw materials are GF (special yarn), UP (unsaturated resin), low shrinkage additives, MD (filler) and various additives. SMC composite materials and SMC composite molded products have excellent electrical insulation properties, mechanical properties, thermal stability, chemical resistance and corrosion resistance, so the application range of SMC composite products is quite wide.
Features of SMC composite material hydraulic press:
1) The hydraulic press for SMC composite material has a heating function. It adopts electric heating of mold or mold temperature controller for heating.
2) SMC composite material hydraulic press is equipped with a mold opening cylinder with mold opening and exhaust functions. It makes SMC composite material fully integrated, and the strength reaches the performance requirements.
3) SMC composite material hydraulic press can also be equipped with external ejection and core pulling, blowing system, and vacuum system, especially for producing precision SMC composite material products such as home appliance shells and auto parts.
4) Since the molds for SMC composite material compression molding are generally heavy, even up to more than ten tons, our hydraulic press can also be equipped with a mold-changing trolley for easy loading, unloading, and changing molds.
5) Equipped with a green environmental protection system. It is equipped with a smoke collection hood to treat the exhaust gas centrally and meet the requirements of the environmental protection department.
6) Precision SMC composite products such as home appliance shells and auto parts have high precision requirements for SMC composite material hydraulic press, requiring a four-corner levelling system.
Application of SMC composite material molding hydraulic press :
You can rest assured of buying customized new generation SMC moulding Zhengxi hydraulic press from us. This hydraulic press is specially used for thermoforming of thermosetting composite materials. It is mainly used for SMC, BMC, DMC, GMT, LFT-D, LFT-G and other materials. These materials are widely used in ships, automobiles, electric power appliances, rail transportation, home decoration and bathroom, aerospace, mould trial production and other fields.
Optional configuration:
● Electric mold changing trolley
● Four-corner levelling function/parallelism levelling system
● External core pulling/ejection circuit
● Industrial oil cooler/condensate circulation system
● Mold temperature controller
● Quick mold clamping device
